| Print Method |
Thermal inkjet with dye or pigment ink |
| Print Resolution |
1200 × 2400 dpi |
| Print Speeds |
Up to 132 mm (5.2") per second |
| Inks |
Individual cartridges for cyan, magenta, yellow and black |
| Printhead |
User replaceable, multi-use printhead |
| Colours |
16.7 million |
| Colour Matching |
Standard Colour Matching |
| Print Width |
20 mm – 210 mm (0.78" – 8.25") |
| Media Width |
30 mm – 212 mm (1.18" – 8.375") |
| Print Length |
max. 1219.20 mm (48") |
max. 1219.20 mm (48")
Peeler output: standard 160 mm, 180 mm (optional) & larger upon request
|
| Media Types |
Roll-fed pressure-sensitive labels, roll-fed tags, fan-fold labels or tags |
| Media Sensing |
Moveable see-through sensor for die-cut labels; reflective sensor for labels and tags with black mark (bottom); can use continuous and pre-printed labels and tags |
| Media Feed |
External |
| Supply Roll |
250 mm (9.84") maximum outer diameter on 76 mm (3") core |
| Ink Level Warning |
Calculates actual number of prints remaining based upon ink usage of graphics being printed. |
| Operating Systems |
Windows 7 and higher |
Data Interface/
Connections |
USB 2.0, wired Ethernet, 24 V PLC |
| Label Design Software |
NiceLabel Free DTM Edition and BarTender UltraLite DTM Edition* |
| Power Requirements |
100 V – 240 V AC (50/60 Hz), 32 V DC, 50 W |
| Certifications |
CE, RoHs |
| Weight |
15 kg |
| Dimensions (W × H × D) |
486 mm × 207 mm × 330 mm |
| What's in the Box |
CLP2200e Colour Label Printer, a set of CMYK inks, a user-replaceable printhead, CLP2200e Unwinder, one 152.4 mm × 101.6 mm (6" × 4") DTM Paper Semi Gloss (dye) or DTM Paper Matte (pigment) starter roll, USB 2.0 cable, EU power cord and instructions** |
CLP2200ep Colour Label Printer, a set of CMYK inks, a user-replaceable printhead, CLP2200ep Unwinder, one 152.4 mm × 101.6 mm (6" × 4") DTM Paper Semi Gloss (dye) or DTM Paper Matte (pigment) starter roll, USB 2.0 cable, EU power cord and instructions** |
| Recommended Accessories |
DTM Print Label Re-/Unwinders |
DTM Print Label Rewinders for the liner waste |
| Warranty |
36 months (after product registration, for devices purchased in EU/EFTA countries and UK) |
| Manufacturer |
DTM Print GmbH |
